10 Print Attachments
10.1 Overview ¶
The Print Attachments task prints the attachments of incoming emails directly on a configured printer. Typical use cases include sending invoices to the accounting mailbox with automatic printout or printing delivery notes for the shipping department.
The task is organized into several tabs: General, Printer Settings, Regular Attachments (filter), Embedded Images (optional), and ZIP Archives.
Profile settings, Print Attachments task: printer selection, attachment filter and scaling options
10.2 “General” tab ¶
10.2.1 Printer ¶
Selection of the printer from the list of printers configured under Program Options -> Printers (see chapter 40.14). If the desired printer has not yet been created, the New Printer… button helps create one directly.
Tip: Set up printers under Program Options as logical units (e.g. “Accounting-B/W”, “Shipping-Color”). Multiple profiles can use the same printer definition.
10.2.2 Use default printer settings ¶
If enabled, the default settings stored on the printer are used (duplex, tray, page format). The options on the Printer Settings tab are then ignored.
10.2.3 PDF printer (storage location) ¶
If the selected printer is a PDF printer (that is, not a physical printer but a print-to-PDF conversion), additional fields appear for the storage location of the generated PDF files:
| Field |
Description |
| PDF folder |
Destination directory for the generated PDFs, with placeholder support |
| PDF file name |
Schema for the file name, with placeholder support |
| If file already exists |
Rename, overwrite, skip, append date/time |
10.2.4 Process embedded images ¶
If enabled, inline images (images embedded in the message body) are also printed. Otherwise, only files marked as “real” attachments are considered. When enabled, the Embedded Images tab also appears with its own filter criteria.
10.3 “Printer Settings” tab ¶
These settings only take effect if Use default printer settings on the “General” tab is disabled.
10.3.1 Copies ¶
Number of copies (1-999) and the Collated option for the copy order.
10.3.2 Duplex and orientation ¶
| Duplex mode |
Description |
| Default |
Uses the printer’s default setting |
| Simplex |
Single-sided printing |
| Horizontal |
Double-sided, binding on long edge |
| Vertical |
Double-sided, binding on short edge |
Orientation either Portrait or Landscape.
10.3.3 Color printing ¶
Enables color printing. If disabled, the printer prints (if supported) in black and white.
10.3.4 Margins ¶
Four fields for the top/bottom/left/right margins in hundredths of millimeters.
10.3.5 Layout ¶
| Option |
Description |
| Auto-rotate pages |
Rotates portrait or landscape pages so that they fit the paper optimally |
| Center content |
Aligns the content in the center of the print page |
10.3.6 Scaling ¶
| Mode |
Description |
| Fit to page |
Scales to the full printable area |
| Actual size |
Keeps the original size (no scaling) |
| Custom scaling |
Freely selectable percentage (10-400 %) |
10.3.7 Page range ¶
The Page range… button opens a dialog for selecting the pages to print - for example “Page 1 only” or “Pages 1-5, 8”.
10.3.8 Other options ¶
| Option |
Description |
| Print only first attachment per name |
If multiple attachments have an identical name, only the first one is printed |
| Print images at actual size |
Does not scale images to the page size |
| Shrink oversized images |
Only shrinks images that are larger than the page |
| Convert Office files to PDF |
Converts Word/Excel files to PDF before printing |
10.3.9 Font for plain-text attachments ¶
Font name, size, and the options Bold, Italic, and Underlined for TXT attachments.
10.4 “Regular Attachments” tab ¶
Filter criteria for the attachments to be printed - analogous to the “Attachment Filter” tab of the Save Attachments task (see chapter 9.3). Fields include file name, file type, file size, image width, image height, and e-invoice type.
10.5 “Embedded Images” tab ¶
Visible when the Process embedded images option is enabled on the “General” tab. Filter criteria configurable separately, as for regular attachments.
10.6 “ZIP Archives” tab ¶
Also prints files from ZIP archives, if enabled.
| Field |
Description |
| Print ZIPs |
Enables printing of ZIP contents |
| Password |
Optional password for encrypted ZIPs |
| File filter (contains / does not contain) |
Filter on names of files inside the ZIP |
10.7 Use case ¶
Print incoming invoices automatically - Printer: accounting printer, default settings. Filter: PDF only, name contains “Invoice”. Collated + duplex horizontal.
10.8 Tip ¶
- Test profiles with a PDF printer (instead of a physical printer) let you check print results without consuming paper
